Electric winch,which is drum winding wire rope, is one kinds of small lifting equipment. It can be vertical, horizontal and
inclined lifting or pulling heavy objects.Not only be used alone but be used for crane manufacturing as main hoisting
mechanism .Reasonable designed structure ,easy operation and excellent working performance
Electric winch is widely
used in construction site, mine, factory, port pier, crane manufacturing ,etc material lifting or traction.
| Basic Parameters | Rated Load | Rope Speed | Capacity of Rope | Rope Diameter | Motor Power | Dimension | Total Weight |
| Model | KN | m/min | m | mm | KW | mm | kg |
| JK0.5 | 5 | 22 | 190 | 7.7 | 3 | 620×701×417 | 200 |
| JK1 | 10 | 22 | 100 | 9.3 | 4 | 620×701×417 | 300 |
| JK1.6 | 16 | 24 | 150 | 12.5 | 5.5 | 945×996×570 | 500 |
| JK2 | 20 | 24 | 150 | 13 | 7.5 | 945×996×570 | 550 |
| JK3.2 | 32 | 25 | 290 | 15.5 | 15 | 1325×1335×840 | 1011 |
| JK3.2B | 32 | 30 | 250 | 15.5 | 22 | 1900×1738×985 | 1500 |
| JK5 | 50 | 30 | 300 | 21.5 | 30 | 1900×1620×985 | 2050 |
| JK5B | 50 | 25 | 210 | 21.5 | 22 | 2250×2500×1300 | 2264 |
| JK8 | 80 | 25 | 160 | 26 | 45 | 1533×1985×1045 | 3000 |
| JK10 | 100 | 30 | 300 | 30 | 55 | 2250×2500×1300 | 5100 |
Conponents of High Speed JK electric Winch price
1. Q: What's your MOQ?
A: 1 Set;
2. Q: What's your package?
A: Main body in plywood box or in plastic woven cloths; Spare parts in plywood boxes;
3. Q: What's your delivery period?
A: Within 10/25/40 days after your prepayment received; exact period should be based on detailed requirements and
actual period;
4. Q: What's your warranty period?
A: 12 months from winches accepted;
5. Q: Do you have engineer oversea installation service?
A: Yes; We have;
6. Q: What kinds of products do you have?
A: All kinds of industrial electric winch (especially non-standard); Overhead Crane; Gantry Crane, Electric Hoist;
Screw Hoist; Radial/Flat Gate Hoist; Steel Gate; etc.
7. Q: Could we buy spare parts in local once they are out of work?
A: Our main electrical parts brand is Siemens or Schneider brand; it's very easy to buy all the world. But if there is
any difficulty, we can post to you by express, such as DHL, UPS, FEDEX, Aramex, etc.
8. Q: Do you provide lift tools?
A: Yes, we can provide any kinds of lift tools such as lift sling belt, lift clamp, grab, magnet , pulley blocks, hook,
lock catch, wire rope, fiber rope, etc.
9. Q: Could your winches drag inclined?
A: Yea, our electric winches could drag horizontal, drag inclined, hoisting vertical.
