5 ton 8 ton Electric Capstan Winch for Sale
The electric winch is mainly applied to hoisting, pulling and loading or unloading the weight. For example, it can be used to mount and dismount large and medium-sized concrete and steel structure and machinery equipment. Also, it could be utilized as the lifting mechanism of hoisting machinery. This product features orderly-arranged steel wire ropes, safe slinging, smooth transmission and convenient maintenance. This product can be used for the equipment installation in bridge building, port construction, wharf construction, shipyard building and other large-scale factories and mines projects. We can also custom design and build the winch to your special requirements. JK fast speed electric winchIf you need to lift and pull heavy loads with a higher efficiency, a high speed winch may be a better choice. Line speed of the winch ranges from 20m/min to 35m/min. This type of winch equipment helps you do the job quickly and safely. It can also be specifically designed to fit on cranes and derricks, replacing an electric hoist as the main hoisting mechanism.
- Loading capacity: 0.5~60 t
- Rope capacity: 10~1500 m
- Working speed: 20~35 m/min; (single speed or dual speed)
- Power supply: 220-690V, 50/60HZ, 3Phase
JM slow speed electric winchThe slow speed winch, as the name implies, works at a slow speed that ranges from 5m/min to 20m/min. This type of winch provides more precise load control and accurate positioning. It is ideal for various engineering projects. With marine duty design, the winch can also be used on the boat and on the shore for anchoring, mooring or towing purposes.
|JCYC-JK Electric winch|| || || || || || |
|Model||Cable rated pull(kg)||Cable rated speed(m/min)||Wire rope dia. (Φmm)||Wire rope length(m)||Drum(mm) Dia(Φ)||Motor power(kw)|
- Loading capacity: 0.5~200 t
- Rope capacity: 10~2000 m
- Working speed: 5~20 m/min;(single speed or dual speed)
- Power supply: 220-690V, 50/60HZ, 3Phase
|JCYC-JM Electric winch|| || || || || || |
|Model||Cable rated pull(kg)||Cable rated speed(m/min)||Wire rope (Φmm)||Wire rope length(m)||Drum(mm) Dia(Φ)||Motor power(kw)|
|JM30||30000||9|| Φ54||450|| Φ900*1500||63|
JM/JK electric winch is a small and light weight winch machine with simple structure. It mainly consists of electric motor, rope, drum, transmission system, brake and control system.
Electric motor - for general engineering winches, IP44 protected electric motor is used.
Steel rope - there are two main factors involving in the rope capacity, length and diameter. Wire rope and synthetic rope are available for you to choose from.
Drum - it is a cylindrical device designed to store the rope as well as wind the rope in and out during winching operation.
Transmission system - different types of transmission system are available, including worm gearbox, spur gearbox and planetary gearbox. The selection of winch transmission is determined by your required efficiency and how much torque is going to be transmitted.
Brake - the winch can be delivered with motor brake, transmission brake and drum brake.
Control system - the winch is normally equipped with a control box that comprises up/down push buttons and emergency stop. Remote control is available for a much safer winching operation.
Questions before make quotation:
1. Purpose of the winch, lifting or pulling?
2. Where will you use the winch? construction, mine or marine?
4. Rope volume?
5. Requirement for rope speed?
7. Any other specific request such as double speed, additional equipment?
The more detail, the more accurate quotation.
--- Before Sale Service :
1. Quotation: Helping customer analyze lifting plan. So that making quotation strictly acoording to customers' speicic requirements;
2. Sign Contract: Adjust the terms of the contract according to the customer's requirements, and the customer's interests are guaranteed;
3. Quality Control: Strictly arange production based on signed contract;
4. Delivery Time: Strictly guarantee the delivery time according to contract;
5. Photos and documents: Send photos and prepare related documents after finish production. Provide DHL or Fedex express to send original documents.
--- After Sale Service :
1. Response: Fast reply all questions from our customers on line or by email/phone call all time 24h.
2. Installation or maintainess problems: Manuals will sent along with products. Please operate according to manuals. If any question, please contact us in time.
3. Quality problems: Our factory is responsible for any problems if it is caused by our reasons (Such as give you free new parts to repair it or give enough some compensation cost to you) ;
1. Questions before quotation?
Capacity? Lifting height? Voltage? Quantity? The more details the more accurate price quotation. Thank you.
2. What about the payment term&price term?
As usual, we accept T/T, L/C as the payment term, and the price term, FOB&CIF&CFR etc are ok.
3. What's the delivery time?
Usually, we will delivery the goods within 15-20 working days, but this is aim at 1-10 pieces products, if more quantity, it depends.
4. Are we a manufacturer&factory or trading Company?
Chongqing Shanyan Crane Machinery Co.,ltd is a manufacturer in Chongqing, China, we have specialized in crane&hoist over 30 years, our high quality products were welcomed in many countries.
5. Which country have you exported your products?
Actually all over the world. Our company have rich export experience. And we have professional logistics team, we will bring you good service purchasing experience.
6. How about the warranty and maintenance of the goods?
We supply 1 year warranty for our goods. And 24 hours online support services. If need, we can also send our technician to your country for installation and maintenance.
